KW Leveling suspension V3 for 05/2018- Audi A6 Avant (4A5, C8)

35208100DG

Stock: Backorder Available

AU$5,069.00 Inc GST

Description

Description

Suspension V3 Leveling

Invisible - but you can feel it!

The KW Leveling suspensions are ideal for drivers who are not looking for maximum lowering, but seeking the driving dynamics and comfort of a KW Coilover suspension in combination with the almost original manufacturer’s series floor clearance.

The KW Leveling suspensions focus on the combination of increased driving dynamics and comfort in connection with a minimum lowering or, if desired, raising of the suspension. The KW Leveling suspensions are the ideal retrofit suspensions for frequent drivers on poorly developed roads or drivers that use their car mainly in metropolises and urban areas than have numerous speed bumps. The progressive suspension springs are designed to give their spring rate a plus in driving comfort. Accordingly, the KW Leveling suspensions have an adjustable, comfort-oriented basic damper tuning. If required, the KW leveling enables an adapted level regulation in the range of + 5 - 20 mm.

The KW V3 Leveling suspension is the ideal retrofit option for drivers who are looking for everyday practicality, increased rolling comfort, and sportiness. The separately adjustable dampers in compression and rebound with their "TVR-A" and "TVC-A" technology allow extensive damper tuning. This makes it easy to additionally influence the steering behavior, directional stability, tire grip, and handling characteristics significantly for safe control at the limit and increased driving comfort.

- Rebound and compression damping adjustable damper technology
- Stainless steel technology "inox-line"
- Individual, continous level regulation
- tested adjustment range
- High quality components for a long life
- Complete documentation for an easy handling
- Adjustable rebound damping with 16 exact clicks
- Adjustable compression damping with 12 exact clicks
- Unique, independent from each other working damping force adjustment

Fitment

Fitment

MakeModelTypeBody TypeAspirationKWCCMCylDrivetrain
AUDIA6 Avant (F2) C8, 4A5 05/2018-30 TDI Mild HybridEstateDiesel/Electro10019684Front Wheel Drive
AUDIA6 Avant (F2) C8, 4A5 05/2018-35 TDI Mild HybridEstateDiesel/Electro12019684Front Wheel Drive
AUDIA6 Avant (F2) C8, 4A5 05/2018-35 TDI MILD HYBRIDEstateDiesel/Electro12019684Front Wheel Drive
AUDIA6 Avant (F2) C8, 4A5 05/2018-40 TDI Mild HybridEstateDiesel/Electro14019684Front Wheel Drive
AUDIA6 Avant (F2) C8, 4A5 05/2018-40 TDI Mild HybridEstateDiesel/Electro15019684Front Wheel Drive
AUDIA6 Avant (F2) C8, 4A5 05/2018-40 TFSIEstatePetrol14019844Front Wheel Drive
AUDIA6 Avant (F2) C8, 4A5 05/2018-40 TFSIEstatePetrol15019844Front Wheel Drive
AUDIA6 Avant (F2) C8, 4A5 05/2018-45 TFSIEstatePetrol18019844Front Wheel Drive
AUDIA6 Avant (F2) C8, 4A5 05/2018-45 TFSI Mild HybridEstatePetrol/Electric18019844Front Wheel Drive
AUDIA6 Avant (F2) C8, 4A5 05/2018-45 TFSI Mild HybridEstatePetrol/Electric19519844Front Wheel Drive

Media

Media

Parts Approval: PDF

Installation Instruction: PDF

Adjustment Manual: PDF

Disclaimer

Disclaimer

Product Disclaimers:

  • Note 67: Dampers are adjusted by easily operating adjustment wheels. Rebound is only adjustable if the top of the piston rod is accessible. This will depend on the vehicle construction.
  • Note 418: Only for cars with a clamp diameter of 53mm on the front axle
  • Note 2: Height adjustable front and rear axles (front axle threaded strut housings, rear axle adjustable springs + dampers)
  • Note 37: For cars which have electronic dampers, make sure they are shut down. Specific electronical damper shut-downs are available from KW. Please check our accessories list
  • Note 8: Not for vehicles with automatic self leveling control / air suspension
