KW Leveling suspension V3 for 09/2016- BMW 5 (G30, F90)

35208200BU

Stock: Backorder Available

AU$5,139.00 Inc GST

Description

Description

Suspension V3 Leveling

Invisible - but you can feel it!

The KW Leveling suspensions are ideal for drivers who are not looking for maximum lowering, but seeking the driving dynamics and comfort of a KW Coilover suspension in combination with the almost original manufacturer’s series floor clearance.

The KW Leveling suspensions focus on the combination of increased driving dynamics and comfort in connection with a minimum lowering or, if desired, raising of the suspension. The KW Leveling suspensions are the ideal retrofit suspensions for frequent drivers on poorly developed roads or drivers that use their car mainly in metropolises and urban areas than have numerous speed bumps. The progressive suspension springs are designed to give their spring rate a plus in driving comfort. Accordingly, the KW Leveling suspensions have an adjustable, comfort-oriented basic damper tuning. If required, the KW leveling enables an adapted level regulation in the range of + 5 - 20 mm.

The KW V3 Leveling suspension is the ideal retrofit option for drivers who are looking for everyday practicality, increased rolling comfort, and sportiness. The separately adjustable dampers in compression and rebound with their "TVR-A" and "TVC-A" technology allow extensive damper tuning. This makes it easy to additionally influence the steering behavior, directional stability, tire grip, and handling characteristics significantly for safe control at the limit and increased driving comfort.

- Rebound and compression damping adjustable damper technology
- Stainless steel technology "inox-line"
- Individual, continous level regulation
- tested adjustment range
- High quality components for a long life
- Complete documentation for an easy handling
- Adjustable rebound damping with 16 exact clicks
- Adjustable compression damping with 12 exact clicks
- Unique, independent from each other working damping force adjustment

Fitment

Fitment

MakeModelTypeBody TypeAspirationKWCCMCylDrivetrain
BMW5 (G30, F90) F5LM, G5L 09/2016-518 dSaloonDiesel10019954Rear Wheel Drive
BMW5 (G30, F90) F5LM, G5L 09/2016-518 dSaloonDiesel11019954Rear Wheel Drive
BMW5 (G30, F90) F5LM, G5L 09/2016-518 d Mild-HybridSaloonDiesel/Electro10019954Rear Wheel Drive
BMW5 (G30, F90) F5LM, G5L 09/2016-518 d Mild-HybridSaloonDiesel/Electro11019954Rear Wheel Drive
BMW5 (G30, F90) F5LM, G5L 09/2016-520 dSaloonDiesel12019954Rear Wheel Drive
BMW5 (G30, F90) F5LM, G5L 09/2016-520 dSaloonDiesel14019954Rear Wheel Drive
BMW5 (G30, F90) F5LM, G5L 09/2016-520 d Mild-HybridSaloonDiesel/Electro12019954Rear Wheel Drive
BMW5 (G30, F90) F5LM, G5L 09/2016-520 d Mild-HybridSaloonDiesel/Electro14019954Rear Wheel Drive
BMW5 (G30, F90) F5LM, G5L 09/2016-520 E PLUG-IN-HYBRIDSaloonPetrol/Electric12019984Rear Wheel Drive
BMW5 (G30, F90) F5LM, G5L 09/2016-520 E PLUG-IN-HYBRIDSaloonPetrol/Electric15019984Rear Wheel Drive
BMW5 (G30, F90) F5LM, G5L 09/2016-520 iSaloonPetrol12019984Rear Wheel Drive
BMW5 (G30, F90) F5LM, G5L 09/2016-520 iSaloonPetrol12515974Rear Wheel Drive
BMW5 (G30, F90) F5LM, G5L 09/2016-520 iSaloonPetrol13519984Rear Wheel Drive
BMW5 (G30, F90) F5LM, G5L 09/2016-520 iSaloonPetrol15519984Rear Wheel Drive
BMW5 (G30, F90) F5LM, G5L 09/2016-520 i Mild-HybridSaloonPetrol/Electric12019984Rear Wheel Drive
BMW5 (G30, F90) F5LM, G5L 09/2016-520 i Mild-HybridSaloonPetrol/Electric13519984Rear Wheel Drive
BMW5 (G30, F90) F5LM, G5L 09/2016-525 dSaloonDiesel15519954Rear Wheel Drive
BMW5 (G30, F90) F5LM, G5L 09/2016-525 dSaloonDiesel17019954Rear Wheel Drive
BMW5 (G30, F90) F5LM, G5L 09/2016-530 dSaloonDiesel19529936Rear Wheel Drive
BMW5 (G30, F90) F5LM, G5L 09/2016-530 d Mild-HybridSaloonDiesel/Electro18329936Rear Wheel Drive
BMW5 (G30, F90) F5LM, G5L 09/2016-530 d Mild-HybridSaloonDiesel/Electro21029936Rear Wheel Drive
BMW5 (G30, F90) F5LM, G5L 09/2016-530 e Plug-in-HybridSaloonPetrol/Electric12019984Rear Wheel Drive
BMW5 (G30, F90) F5LM, G5L 09/2016-530 e Plug-in-HybridSaloonPetrol/Electric13519984Rear Wheel Drive
BMW5 (G30, F90) F5LM, G5L 09/2016-530 e Plug-in-HybridSaloonPetrol/Electric17019984Rear Wheel Drive
BMW5 (G30, F90) F5LM, G5L 09/2016-530 e Plug-in-HybridSaloonPetrol/Electric18519984Rear Wheel Drive
BMW5 (G30, F90) F5LM, G5L 09/2016-530 e Plug-in-HybridSaloonPetrol/Electric20019984Rear Wheel Drive
BMW5 (G30, F90) F5LM, G5L 09/2016-530 e Plug-in-HybridSaloonPetrol/Electric21519984Rear Wheel Drive
BMW5 (G30, F90) F5LM, G5L 09/2016-530 iSaloonPetrol18019984Rear-Wheel Drive
BMW5 (G30, F90) F5LM, G5L 09/2016-530 iSaloonPetrol18519984Rear Wheel Drive
BMW5 (G30, F90) F5LM, G5L 09/2016-530 i Mild-HybridSaloonPetrol/Electric18019984Rear-Wheel Drive
BMW5 (G30, F90) F5LM, G5L 09/2016-530 i Mild-HybridSaloonPetrol/Electric18519984Rear Wheel Drive
BMW5 (G30, F90) F5LM, G5L 09/2016-540 iSaloonPetrol25029986Rear Wheel Drive
BMW5 (G30, F90) F5LM, G5L 09/2016-540 iSaloonPetrol26529986Rear Wheel Drive
BMW5 (G30, F90) F5LM, G5L 09/2016-540 i Mild-HybridSaloonPetrol/Electric24529986Rear Wheel Drive

Media

Media

Parts Approval: PDF

Installation Instruction: PDF

Adjustment Manual: PDF

Disclaimer

Disclaimer

Product Disclaimers:

  • Note 37: For cars which have electronic dampers, make sure they are shut down. Specific electronical damper shut-downs are available from KW. Please check our accessories list
  • Note 67: Dampers are adjusted by easily operating adjustment wheels. Rebound is only adjustable if the top of the piston rod is accessible. This will depend on the vehicle construction.
  • Note 1: Height adjustable on the front and rear axles (threaded strut housings)
