ST Coilover X Kit for 06/2004+ BMW 5 Series Touring

13220045
ST Suspension

Stock: Backorder Available

AU$2,259.00 Inc GST

Description

Description

Coilovers ST X galvanized steel (with fixed damping)

Need to get low? ST coilovers feature a continuous thread construction for height adjustment from moderate to eXtreme! Each coilover is manufactured by KW Automotive and their expertise and know how ensures maximum quality and fantastic driving dynamics.

Once installed, the ST X coilover can be easily adjusted using a polyamide ring on the galvanized, multiple-sealed strut. Adjustment is different for each car, but typically you can expect between 35 and 65mm of lowering on both the front and rear axles. For lowered cars as standard (such as the BMW E9x 3-series) the ST X coilover features a range of 30 to 60mm (front axle) and 25-55mm (rear axle).

Improved driving dynamics and handling
Designed in conjunction with KW Germany, ST X coilovers deliver a sporty handling by reducing the car’s bodyroll during compression as well as improving agility when driving fast. The high-quality production of each ST X coilover includes a low-friction and pressure resistant housing alongside a chrome-plated piston rod for maximum longevity. A mono block guide and ST seal package ensures the twin-tube dampers remain free of dirt particles in all weather conditions.

Lowering with St\Tyle: the ST X coilovers
- Individual lowering within the tested adjustment range
- Front and rear axle thread adjustment (when possible)
- Galvanized coilover struts with additional coating for optimized corrosion protection
- Complete solution with adjustable spring plate, spring system and bumpers with dust protection
- Powerful twin-tube dampers with high-quality components for maximum longevity

Fitment

Fitment

MakeModelTypeBody TypeAspirationKWCCMCylDrivetrain
BMW5 Touring (E61) 560L, 560X, M5/M6, M560 03/2004-12/2010520 dEstateDiesel11019954Rear Wheel Drive
BMW5 Touring (E61) 560L, 560X, M5/M6, M560 03/2004-12/2010520 dEstateDiesel12019954Rear Wheel Drive
BMW5 Touring (E61) 560L, 560X, M5/M6, M560 03/2004-12/2010520 dEstateDiesel13019954Rear Wheel Drive
BMW5 Touring (E61) 560L, 560X, M5/M6, M560 03/2004-12/2010520 iEstatePetrol12019954Rear Wheel Drive
BMW5 Touring (E61) 560L, 560X, M5/M6, M560 03/2004-12/2010520 iEstatePetrol12519954Rear Wheel Drive
BMW5 Touring (E61) 560L, 560X, M5/M6, M560 03/2004-12/2010523 iEstatePetrol13024976Rear Wheel Drive
BMW5 Touring (E61) 560L, 560X, M5/M6, M560 03/2004-12/2010523 iEstatePetrol14024976Rear Wheel Drive
BMW5 Touring (E61) 560L, 560X, M5/M6, M560 03/2004-12/2010523 iEstatePetrol14024976Rear Wheel Drive
BMW5 Touring (E61) 560L, 560X, M5/M6, M560 03/2004-12/2010525 dEstateDiesel12024976Rear Wheel Drive
BMW5 Touring (E61) 560L, 560X, M5/M6, M560 03/2004-12/2010525 dEstateDiesel13024976Rear Wheel Drive
BMW5 Touring (E61) 560L, 560X, M5/M6, M560 03/2004-12/2010525 dEstateDiesel14529936Rear Wheel Drive
BMW5 Touring (E61) 560L, 560X, M5/M6, M560 03/2004-12/2010525 iEstatePetrol14124946Rear Wheel Drive
BMW5 Touring (E61) 560L, 560X, M5/M6, M560 03/2004-12/2010525 iEstatePetrol15524976Rear Wheel Drive
BMW5 Touring (E61) 560L, 560X, M5/M6, M560 03/2004-12/2010525 iEstatePetrol15529966Rear Wheel Drive
BMW5 Touring (E61) 560L, 560X, M5/M6, M560 03/2004-12/2010525 iEstatePetrol16024976Rear Wheel Drive
BMW5 Touring (E61) 560L, 560X, M5/M6, M560 03/2004-12/2010525 iEstatePetrol16029966Rear Wheel Drive
BMW5 Touring (E61) 560L, 560X, M5/M6, M560 03/2004-12/2010530 dEstateDiesel15529936Rear Wheel Drive
BMW5 Touring (E61) 560L, 560X, M5/M6, M560 03/2004-12/2010530 dEstateDiesel16029936Rear Wheel Drive
BMW5 Touring (E61) 560L, 560X, M5/M6, M560 03/2004-12/2010530 dEstateDiesel17029936Rear Wheel Drive
BMW5 Touring (E61) 560L, 560X, M5/M6, M560 03/2004-12/2010530 dEstateDiesel17329936Rear Wheel Drive
BMW5 Touring (E61) 560L, 560X, M5/M6, M560 03/2004-12/2010530 iEstatePetrol19029966Rear Wheel Drive
BMW5 Touring (E61) 560L, 560X, M5/M6, M560 03/2004-12/2010530 iEstatePetrol20029966Rear Wheel Drive
BMW5 Touring (E61) 560L, 560X, M5/M6, M560 03/2004-12/2010530 iEstatePetrol20029966Rear Wheel Drive
BMW5 Touring (E61) 560L, 560X, M5/M6, M560 03/2004-12/2010535 dEstateDiesel20029936Rear Wheel Drive
BMW5 Touring (E61) 560L, 560X, M5/M6, M560 03/2004-12/2010535 dEstateDiesel21029936Rear Wheel Drive
BMW5 Touring (E61) 560L, 560X, M5/M6, M560 03/2004-12/2010545 iEstatePetrol24543988Rear Wheel Drive
BMW5 Touring (E61) 560L, 560X, M5/M6, M560 03/2004-12/2010550 iEstatePetrol27047998Rear Wheel Drive

Media

Media

Parts Approval: PDF
Installation Instruction: PDF

Disclaimer

Disclaimer

Product Disclaimers:

  • Note 42: In combination with orginal wheels and tyres, wheelspacers might be necessary
  • Note 185: For the rear axle sport shock absorbers will be supplied, the factory air spring will maintain. The lowering of the vehicle needs to be done according to the instructions

  • Product Question
